GB DC gun
Technical Parameters
-
Rated voltage: 750V/1000V DC
- Rated current: 80A/125A/200A/250A
- Withstand voltage: 3500V AC 1min
- Insulation resistance: 1000MΩ(1min 1000V DC)
- Insertion and extraction force: ＜140N
- Plugging times: 10000
- Protection grade: Ip67
- Flame retardant rating: UL94-V0
- Ambient temperature: -40℃~+85℃
- Standard: GB/T20234.1、GB/T20234.3
Features and Characteristics
- Comfortable and convenient to use
- Safe and reliable
- Passed national CQC certification and mandatory inspection report
- Optional crimping and ultrasonic welding processes
- Customizable appearance color and line length according to user requirements
Application
Electric Vehicles,Charging Equipment
Product Dimensions
